Stand Post Type Water Monitor

Name: Stand Post Type Water Monitor
Brand: SAINATH FIRE
Price: 15.00 INR
Availability: InStock

Get a Price/Quote

MOQ : 5 Pieces

Stand Post Type Water Monitor Specification

Working Temperature
Up to 60C

Connectivity Type
Flanged Inlet

Voltage
Not Required (Manual Operation)

Control Type
Rotary Handle with Vertical & Horizontal Movement

Technology
Manual Jet/Spray Nozzle

Coverage Area
Up to 55 meters (Jet Spray)

Features
360 Rotation, Adjustable Jet and Spray, Corrosion Resistant, Easy Maintenance

Fire Class
Class A, B, C Fires

Operating Pressure
7-12 kg/cm

Mounting Type
Stand Post / Floor Mounted

Coating Type
Red Epoxy Powder Coated / Hot Dip Galvanized

Shape
Vertical Stand Post

Fire Extinguisher Type
Water Monitor (Direct Discharge)

Installation Type
Free Standing / Flanged Base Mounting

Application
Fire Fighting, Industrial, Oil & Gas, Petrochemical Plants

Max Flow Rate
1750 LPM to 3500 LPM

Diameter
63mm (2.5 inch) / 75mm (3 inch) / 100mm (4 inch)

Capacity
1750-3500 LPM

Pressure
7 kg/cm to 12 kg/cm

Finish
Epoxy Powder Coated / Hot Dip Galvanized

Colour
Red (RAL 3000) or as specified

Inlet Connection
Flanged (as per IS/ANSI/DIN)

Discharge Pattern
Jet & Fog (Selectable)

Usage
Outdoor / Indoor

Height
Single/Double/Custom as Required

Material
Carbon Steel / Stainless Steel

Nozzle Type
Water Jet / Fog Nozzle

Rotation
360 Degree Horizontal, 120 Degree Vertical

Weight
Approx. 32-46 kg (Depending on Size)

Testing Pressure
21 kg/cm² (Hydrostatic)

Stand Post Type Water Monitor Trade Information

Minimum Order Quantity
5 Pieces

FOB Port
MUMBAI

Supply Ability
50 Pieces Per Week

Delivery Time
1 Week

Sample Available
Yes

Main Export Market(s)
Australia, North America, South America, Eastern Europe, Middle East, Western Europe, Central America, Asia

Main Domestic Market
All India

About Stand Post Type Water Monitor

We are at the forefront in providing optimum quality of Stand Post Type Water Monitor. This Stand Post Type Water Monitor comprises of swivel joint lock that is made from high-quality brass material. This rigidly constructed water monitor can be rotated easily in horizontal and vertical direction with the help of handle. Jet nozzle and drain valve of the monitor offers stable and high pressure of water for longer time and can be easily reached at longer distance without any difficulty.

Specifications:

Monitor Size: 63MM (2 1/2")
AS Per IS:8442 Type
Base Flange & Elbow 90 Degree & 45 Degree.
Swivel Joint Lock Material Brass
Handle For Horizontal & Vertical Rotation
Jet Nozzle And Drain Valve
360 Degree Horizontal Rotation
Nozzle Size: 32mm
LPM: 10800 , Horizontel Range 49 MTR
AND Vertical Jet 23 MTR.
Flow Rate: 1750 LPM
Pressuer: 7KG/cm2

Efficient Fire Protection Solution

This water monitor is engineered for effective coverage of up to 55 meters, making it well-suited for large industrial spaces and hazardous locations. Its durable construction, adjustable discharge pattern, and high flow rates ensure swift and adaptable fire response, providing enhanced protection and operational safety across varying conditions.

Customizable and User-Friendly

Available in different heights, diameters, and finishes, the Stand Post Type Water Monitor can be tailored to specific site requirements. Its manual operationwithout voltage needand ergonomic rotary handle offer hassle-free control, while the flanged mounting ensures secure installation for both new and retrofit fire safety systems.

FAQs of Stand Post Type Water Monitor:

Q: How is the Stand Post Type Water Monitor installed and what are the mounting options?

A: The water monitor can be securely installed using either a free-standing or flanged base mounting method. Installation involves connecting the flanged inlet to a compatible water supply line, in accordance with IS/ANSI/DIN standards. The vertical stand post shape is ideal for floor or ground mounting in both indoor and outdoor locations.

Q: What types of fires can this water monitor be used for?

A: This device is suitable for fighting Class A, B, and C fires, making it versatile for a range of applications including industrial, oil & gas, and petrochemical plants where diverse fire risks may be present.

Q: When should the jet or fog nozzle settings be used?

A: The jet setting is ideal for targeting and extinguishing distant or high-intensity fires, offering coverage up to 55 meters. The fog setting should be used for broader coverage or to cool surfaces, protect personnel, or contain vapors and smoke.

Q: What maintenance is required for this water monitor?

A: Routine maintenance involves inspecting for corrosion, checking the rotary handle and nozzle movement, and testing hydrostatic pressure (up to 21 kg/cm). The corrosion-resistant materials and finishes ensure longevity and easier upkeep compared to conventional monitors.

Q: Where can this water monitor be deployed?

A: It is suitable for both indoor and outdoor use, commonly installed in industrial sites, hazardous storage facilities, and any high-risk area where fire protection with rapid coverage and strong water discharge is necessary.

Q: How does the monitor provide user benefits during emergencies?

A: The manual operation allows instant activation without power needs. With 360-degree rotation and adjustable vertical movement, operators can quickly direct water flow as needed. Its robust design and high flow rate maximize efficiency, improving firefighting outcomes.
